BeastHobby VR100 5.8GHz 37CH 3" Screen Focus Adjustable Analog FPV Goggle for Drone Racing and Micro Whoops

Check out all our Goggles and our Goggle Modules!

Features

• New Refraction light path design

• Object distance adjustable, could match Myopia degree（0°-700°）

• Low power consumption, working current 350mA

• Super sensitive 5.8GHz receiver module, strong anti-interference, more stable
  signal

• 40 CH modules, channels Auto-Searching

• 3.0 inch 480*320 Screen resolution Highlight IPS screen

• Built in 3.7V/1200mAh Lithium battery

• TYPE-C charging output

• Real-time video return, no time delay

• Support Chinese / English menu

• Support External video signal input

• Support Av signal video output, could connect with the external DVR for recording

Specifications

Item	VR100
Name	5.8G FPV Goggle
Display	Screen: 3.0 inch IPS Highlight screen
	Screen resolution: 480*320
	Ratio: 16:9
	View Angle: 360-degree viewing angle
	Backlight brightness: 500cd/m²
video delay	Less than 10 milliseconds
Interface definition	antenna	SMA male to RP-SMA female
	charging	TYRE-C port charge battery
	headphone	3.5mm AV port available for video input and output
Language	Chinese and English
Power Supply	Power adapter:  suggest use DC5V/1 or DC/5V2A interface
	Capacity: Built in 3.7V/8\1200mAh lithium polymer battery
	Working power:   *working current: 350 mA *one hour charge fully, can be worked nearly 3 hours
Wireless	Frequency Table (MHz)
		CH1	CH2	CH3	CH4	CH5	CH6	CH7	CH8
	Band A	5865	5845	5825	5805	5785	5765	5745	5725
	Band B	5733	5752	5771	5790	5809	5828	5847	5866
	Band E	5705	5685	5665	5645	5885	5905	5925	5945
	Band F	5740	5760	5780	5800	5820	5840	5860	5880
	Band R	5658	5695	5732	5769	5806	5843	5880	5917
Appearance	Dimension:  107mm * 150mm * 75mm
	Weight: 300g without antenna

Includes

• 1 x BeastHobby VR100 5.8GHz 37CH 3" Screen Focus Adjustable Analog FPV Goggle for Drone Racing and Micro Whoops
• 1 x Lens Cleaning Cloth
• 1 x USB Charging Cable
• 2 x Antennas
• 1 x AV data cable
• 1 x Goggle packing bag
• 1 x Carry Case
