Walksnail Mini VTX Module for Avatar HD Mini 1s and Mini 1s Lite
New version of VTX: VTX (V2) changed to Mini VTX V3
(the parameters are the same, USB Cable needs to be purchased separately)
Avatar HD mini 1S lite kit comes with the smaller, lighter and stronger new version VTX board which can be installed in smaller drones.
Don't forget to check out the rest of our Digital Video Transmitters and Walksnail Products!!
Specifications:
- Model VTX For Walksnail Avatar HD Mini 1s And Mini 1s Lite
- Communication Frequency 5.725-5.850GHz
- Transmitter Power (EIRP) FCC:<27dBm;CE:<14dBm;SRRC:<20dBm;
- MIC:<25dBm
- I/O Interface JST1.0*4(Power in)JST0.8*4(USB)
- Mounting Holes 25.5*25.5mm(M2 hole);20*20mm(M3 hole)
- Dimensions 31.5*31.5*9.4mm
- Storage 32G
- Recording 1080p/720p
- Weight 6.8g
- Operating Temperature -20-40℃
- Channels 8
- Wide Power Input 3.1V-13V
- Supported FC System Betaflight; Inav; Fettec; Kiss; ArduPliot
- OSD Canvas mode
- Latency Average latency 22ms
- Antenna 1(IPEX)
Package Includes:
- 1 x Walksnail Mini VTX Module for Avatar HD Mini 1s and Mini 1s Lite
$100.99
Walksnail Mini VTX Module for Avatar HD Mini 1s and Mini 1s Lite—
$100.99
Description
New version of VTX: VTX (V2) changed to Mini VTX V3
(the parameters are the same, USB Cable needs to be purchased separately)
Avatar HD mini 1S lite kit comes with the smaller, lighter and stronger new version VTX board which can be installed in smaller drones.
Don't forget to check out the rest of our Digital Video Transmitters and Walksnail Products!!
Specifications:
- Model VTX For Walksnail Avatar HD Mini 1s And Mini 1s Lite
- Communication Frequency 5.725-5.850GHz
- Transmitter Power (EIRP) FCC:<27dBm;CE:<14dBm;SRRC:<20dBm;
- MIC:<25dBm
- I/O Interface JST1.0*4(Power in)JST0.8*4(USB)
- Mounting Holes 25.5*25.5mm(M2 hole);20*20mm(M3 hole)
- Dimensions 31.5*31.5*9.4mm
- Storage 32G
- Recording 1080p/720p
- Weight 6.8g
- Operating Temperature -20-40℃
- Channels 8
- Wide Power Input 3.1V-13V
- Supported FC System Betaflight; Inav; Fettec; Kiss; ArduPliot
- OSD Canvas mode
- Latency Average latency 22ms
- Antenna 1(IPEX)
Package Includes:
- 1 x Walksnail Mini VTX Module for Avatar HD Mini 1s and Mini 1s Lite
